35Landa PGDC Operator’s Manual 8.916-596.0 - P
Coil
REF PART NO. QTY DESCRIPTION NOTES
1 9.802-014.0 2 NIPPLE, 1/2" X 3" GALV. SCH 80
2 8.706-141.0 1 COUPLING, 1/2"
3 9.802-170.0 1 NIPPLE, 3/8" PLUG STEEL/ZINC FEMALE
4 9.802-883.0 1 INSULATION, FRONT HEAD, NO HOLE
5 9.802-894.0 1 INSULATION, BURNER HEAD, W/HOLE
6 9.802-896.0 1 INSULATION, BLANKET, NO FOIL 24" X 57"
7 8.933-009.0 2 GASKET, BURNER PLATE
8 9.802-902.0 1 INSUL/BLANKET, DIE CUT 28" X 24" X 1"
9 9.802-781.0 2 NUT, 3/8" FLANGE WHIZ LOC, NC
10 9.802-807.0 2 WASHER, FLAT 3/8"
11 8.916-486.0 1 WLMT, BOTTOM WRAP
12 9.803-132.0 2 INSULATION RETAINER PLATE
13 9.802-797.0 8 SCREW, SS #10 X 1/2 HEX HEAD TEK
14 8.912-239.0 1
COIL, LANDA DURA, SCH 80 W/ALUMINIZED
STEEL WRAP
15 9.149-003.0 1 MANIFOLD, COIL OUTLET
16 9.802-043.0 1 ELBOW, 1/2 JIC X 1/2 FEM 90°
17 8.707-381.0 1 RUPTURE DISC ASSY, 8500#
18 9.802-727.0 2 BOLT, 3/8" X 1-3/4" TAP
19 9.802-015.0 1 NIPPLE, 1/2" X 4" GALV. SCH 80
20 9.803-559.0 1 CLAMP,SCREW,9/16"W, 1-1/4"OD, SS
21 9.802-024.0 1 ELBOW, 3/8" MPT x 1/2" FPT STREET, STEE
22 9.802-260.0 26" HOSE, 1/2" PUSH-ON
23 9.196-012.0 1 SCREW, 10-24 X 1/4
24 8.750-097.0 1 THERMOSTAT 240° F
25 9.802-447.0 48" CONDUIT, SPLIT
26 8.706-207.0 1 ELBOW, 3/8" STREET 90°, STEEL
27 8.725-553.0 1 NIPPLE, PIPE 3/8” X 8" SCH 80
28 9.802-171.0 1 COUPLER, 3/8" PLUG, MALE STEEL/ZINC
29 8.706-248.0 1 PLUG, 3/8" ALLEN COUNTER SUNK
