45Landa PGDC Operator’s Manual 8.916-596.0 - P
Landa Sure Fire Burner
REF PART NO. QTY DESCRIPTION NOTES
1 8.919-050.0 1 BURNER HOUSING ASSEMBLY
2 8.751-160.0 1 AIR GUIDE
3 8.754-705.0 1 FUEL PUMP, SUNTEC OL35 12-24 V SOL
- 8.700-759.0 1 FUEL PUMP, SUNTEC A2VA-3106 120 V SOL
- 8.700-760.0 1 FUEL PUMP, SUNTEC A2VA-3106 120 V SOL
4 9.807-348.0 1 LABEL, CLEAR MYLAR
5 9.802-510.0 2 CABLE, TIE, 4" BLACK
6 8.750-541.0 1 AIR BAND
7 8.750-517.0 1 MOTOR,1/6 HP 115V 60HZ
- 8.750-518.0 1 MOTOR,1/6 HP 230V 60HZ
- 8.750-074.0 1 MOTOR,1/7 HP 12VDC AMETEK
8 8.750-543.0 1 COUPLING, FLEX, 1/2" X 5/16"
- 8.751-073.0 1 COUPLING, FLEX, 5/16" X 5/16"
9 8.750-520.0 1 FAN, 4.53" X 2.42",1/2" BORE, F115-62S
- 8.751-072.0 1 FAN, 4.53" X 2.42", .313 BORE, F115-625
10 8.900-083.0 1 100 PSI SNAP CHECK VALVE
11 8.750-547.0 1 CONNECTOR, 37° FLARE X 1/8” NPT, LONG
12 8.750-545.0 1 CONNECTOR, 37° FLARE X 1/8” NPT
13 8.749-000.0 1 FUEL LINE ASSEMBLY
14 8.752-034.0 1 FLANGE, KNA BURNER, 1” TUBE
15 8.752-035.0 1 FLANGE, KNA BURNER, 3” TUBE
16 8.750-539.0 1 GASKET, FLANGE
17 8.751-354.0 1 GASKET, BURNER TUBE
18 8.750-526.0 1 GUN, ELECTRODE/NOZZLE, 3"
19 8.750-525.0 1 GUN, ELECTRODE/NOZZLE, 1"
20 8.717-273.0 1 FUEL NOZZLE 2.00 X 90 B
21 8.750-778.0 1 ELECTRODE, IGNITION, AC
- 8.751-342.0 1 ELECTRODE, IGNITION, DC
22 8.750-779.0 1 CONE, AIR F4
- 8.750-782.0 1 CONE, AIR F6
- 8.750-780.0 1 CONE, AIR F12
- 8.750-781.0 1 CONE, AIR F22
23 8-919-114.0 1 IGNITER, BURNER 120V
- 8-919-115.0 1 IGNITER, BURNER 230V
- 8-919-116.0 1 IGNITER, BURNER 12VDC
24 8.751-165.0 1 PLUG, HOLE 0.875 PLASTIC
25 8.754-905.0 1 GASKET, KNA BURNER PUMP SUNTEC
26 8.751-134.0 1 PLUG, 1/8" NPT X HEX SHOULDER
27 8.918-454.0 1 GASKET, JUNCTION BOX
28 8.750-542.0 1 COVER, JUNCTION BOX
29 8.750-116.0 1 BLOCK, TERMINAL, 5 POLE
