49Landa PGDC Operator’s Manual 8.916-596.0 - P
LT.2 Series Pump
REF PART NO. QTY DESCRIPTION NOTES
17 8.719-008.0 1 COPPER WASHER 3/8
18 8.707-262.0 1 BRASS PLUG 3/8
19 - 6 VALVE SEAT SEE KITS TABLE
20 - 6 VALVE PLATE SEE KITS TABLE
21 - 6 VALVE SPRING SEE KITS TABLE
22 - 6 VALVE CAGE SEE KITS TABLE
23 8.752-830.0 8 HEX SCREW
24 9.802-884.0 8 WASHER
25 9.803-182.0 1 CLOSED BEARING HOUSING
26 9.803-186.0 2 O-RING Ø2.62 X 71.12
27 9.803-160.0 2 ROLLER BEARING
28 8.753-818.0 1 CRANKSHAFT Ø25 (4540)
- 8.752-827.0 1 CRANKSHAFT Ø25 (6036)
29 9.803-167.0 1 CRANKSHAFT KEY
30 8.752-834.0 1 OIL DIP STICK
31 9.803-139.0 1 CRANKSHAFT SEAL
32 9.803-177.0 2 SHIM
33 9.803-181.0 1 BEARING HOUSING
34 8.752-841.0 3 PLUNGER BOLT SEE KITS TABLE
35 8.752-820.0 3 BONDED SEAL SEE KITS TABLE
36 8.753-819.0 3 PLUNGER, 18MM SEE KITS TABLE
37 8.752-823.0 3 COPPER SPACER SEE KITS TABLE
38 8.753-820.0 3 PLUNGER ROD
40 8.752-821.0 3 CONNECTING ROD
41 9.802-889.0 6 SPRING WASHER
42 9.802-937.0 6 CONNECTING ROD SCREW
43 9.803-194.0 1 O-RING Ø2.62 X 152.07
44 8.752-826.0 1 CRANKCASE COVER
45 9.803-906.0 1 O-RING Ø1.78 X 14.00
46 8.707-262.0 1 BRASS PLUG G3/8
47 9.803-202.0 1 SIGHT GLASS G3/4
48 8.752-824.0 5 COVER SCREW
KIT NUMBERS 8.753-821.0 8.753-822.0 8.753-823.0 8.753-824.0 8.752-835.0
KIT DESCRIPTION
Plunger Seals
18 mm
Seal Packing
18 mm
Plunger
18 mm
Complete Valve
Plunger Oil
Seals
ITEMS NUMBERS
INCLUDED
3, 5, 7 3, 4, 5, 6, 7, 34, 35, 36, 37 11, 12, 13 2
NO. OF CYLINDERS KIT
WILL SERVICE
31163
