Keep threading compound off of the first two
pipe threads to avoid having any small pieces of
compound break loose and clog a burner valve
or orifice. Do not use threading compound on
any flare fittings.
For built-in installations, it is recommended that
any flexible pipe used be kept as short as
possible.
Keep last two
threads clean
For freestanding units using natural gas,
LANDMANN strongly recommends using a
flexible NG gas hose w/ quick connect kit that is
available from your local dealer.
Gas Connections
•
A gas shut-off valve must be installed in an
easily accessible location by a qualified plumber.
•
Always keep supply line runs as short as
possible.
LP Gas Connection
Install the factory-supplied hose and regulator assembly as shown. Connect the 3/
8
” flare end of the
hose to the grill coupling using a 3/4” open wrench. Do not apply pipe sealant to the 3/
8
” flare
connection. Connect the regulator to the LP cylinder hand tighten it, do not use a wrench. Check for
leaks using soapy water solution. (See leak test procedure).
18
QQC-1/OPD
TANK
CSA Approved
Propane Regulator
Do not store any
spare LP TankS
within the enclosure
If using a 20 Lb LP tank, an
adequate heat shield must
be installed in between the
grill and LP tank
Connect to gas grill 3/8"
flared inlet fitting
Vents for adequate
ventilation
To Next Page
