Gas Conversion
ï
- First, make sure all control knobs are in the OFF
position,
main gas supply is off and grill is
disconnected from gas source.
- Next, open Lid and remove Warming Rack, Cooking
Grates, and Flame Tamers.
Warming rack
Flame Tamers
Cooking Grates
î
ó Using pliers remove R pins from above flame crossers
ó λ³±ª» Flame crossers
R-pin
Flame crossers
3
- Using pliers remove R pins and main burner
pins from burners.
R-pin
Main burner pins
Main burners
ÐßÎÌÍ Ô×ÍÌñÜ×ßÙÎßÓ
Tools required for assembly:
7mm wrench
Adjustable wrench
Pliers
Phillips screw driver
Orifices - See chart on next page for
your model number and specific
orifices supplied.
1 Orifice Removal Tool
1
5
1
5
33
Conversion label
