Manual radarTOUCH Version 3.4
T. Schwirten LANG AG
14.10.10
Page 10
Figure 14 Adjustment features Deluxe Mounting System (Top view)
Figure 15 Deluxe Mounting System (Side view)
Figure 16 Measurement device attached to the deluxe mounting system
Distance in
Z-Direction
Rotation
Ceiling
Measurement
device
Tilt
M5x45
M5x50
x
y
z
