Lang Radar Touch RT500 - Standard Mounting System

Manual radarTOUCH Version 3.4
T. Schwirten LANG AG
14.10.10
Page 11
3.1.2 Standard mounting system
The standard mounting system is a good solution for most applications.
However, if the installation requires a very high precision you should use the deluxe system.
With the standard mounting system you can adjust the following parameters:
» Tilt in y-Direction
» Rotation angle measurement device compared to the active area
(should be 0°) but only in a small range
Figure 17 Adjustments for standard mounting system
Figure 18 Screws for rotating adjustment
Rotation
Rotation
Tilt
x
y
z
