Network Computing Platforms
included)
1 x mSATA socket via mini-PCIe interface
Networking
LAN
Model-A: 16 x RJ-45 GbE Ethernet ports and 2
x SFP 10G ports
Model-B/C: 8 x RJ-45 GbE Ethernet ports
Controller
Intel i210-AT for RJ-45
Cortina CS4227 PHY for SFP 10G
Management
N/A
NIC Module
space
1 x Slim Type NIC module socket (PCIe Gen3 x
8 interface)
Console
1 x RJ-45 console port
IPMI*
OPMA socket to support IPMI (project-based)
Bypass
3 or 7 pairs (7 in SKU-A; 3 for SKU-B/C/D)
Fan
2 x Cooling fans
Display
LCM
1x character type LCM
LED
POWER/STATUS/HDD
Keypad
4x Keypads
Expansion
2 x PCIe Gen3x4 expansions for upper layer
expansion (Model A/C only)
1 x PCIe Gen3x8 expansion at rear (optional)
TPM
Optional
Thermal
1 x passive heat sink
Physical
Characteristics
Form Factor
1U rackmount
Housing
SPGC
Dimensions
438mm x 320mm x 44mm (W x D x H)
Mounting Options
Rackmount by sliderail (sliderail is optional)
Environment
Operating
Temperature
0℃～40°C
Non-operating
Temperature
-40℃～70℃
Ambient Humidity
5 to 90% (non-condensing)
Power
Input
AC 90 to 264V@47 to 63Hz
Power supply
220W single PSU
Certifications
CE/FCC Class A, RoHS
*The remake about the IPMI support requires changes in BOM and it is based on custom projects. For
requirements about IPMI support, please consult with Lanner representatives.
