3. Take the tray out and prepare to install a SATA 2.5” disk drive.
4. Place the disk drive as shown in the image below. Apply 2 screws for each side of the disk
drive.
5. Place the tray with HDD/SSD installed back to its original spot inside the system.
Remember to aim the two latching holes. Then slide the tray upwards to get it locked by the
two latching spots.
SATA connector this way
