Laser Pico User Manual

Pico rigging manual 2007.doc Page 17 of 28
The angle of the cleat should be adjusted to a “fully up” position. This can be
changed by unscrewing the centre screw and re-assembling to the preferred angle.
1) Attach the traveller system. Take the traveller line, tie a knot in one end, pass it
through the small traveller block and the fairlead on the opposite side. Tie a knot
in the end of the rope.
4.8 Rigging the mainsheet and traveller

Laser Pico Specifications

General

Type	Dinghy
Crew	1-2
Designer	Jo Richards
Length	3.50 m
Hull weight	60 kg
Sail area	5.1 m²
