LaserLine EPS4016 User Manual

ATTENZIONE:
Non installare mai i sensori al di sotto dell’altezza indicata nei punti B1, B2, B3H min
ATTENTION:
NEVER install the sensors under the height indicated in the 1, 2, 3 points.H min BBB
H min= 40cm
50cm
4b
4a
H min= 50cm
3b
INSTALLAZIONE SENSORI / SENSORS INSTALLATION
3b
3a
100°
MAX
B3
80°
MAX
B2
C
25 cm25 cm 30 cm30 cm 25 cm
25 cm
25÷25÷
L MAX=
= L MAX
50cm
90°
MAX
4 b
4a
H min= 40cm
B1
3 b
3a
4b
Pag.4

LaserLine EPS4016 Specifications

Power

supply voltage	10.8 - 3 V, 9 - 30 V
current consumption with active sensor	20 mA max

Operating Environment

range of service temperatures	-30/+0°C, -25/+70°C
frequency of ultrasound	40 KHz
