LaserPro Explorer - Page 8

Mirror 3
Access Panel
Mirror 1
Access Panel
Mirror 3 Prism Mount
1
2
Screw 1 Left and Right
Pivot Screw - do not adjust
Screw 2 Up and Down
Burn Mark From P3
P3 and P4 Burn Mark
Before adjustment
P3 and P4 Burn Mark
After adjustment
Remember to always wear safety glasses while doing any open beam tests.
7
Pivot
