Initial Set-Up
Hose Spring Installation
3
3-4 Lastec//021819 Initial Set-Up
3.2 Hose Spring Installation
Follow the procedures listed below in sequence to assemble the hose spring from the
traction unit to the deck:
1. Attach one of the provided tie wraps around the hoses that are connected from the deck
to the traction unit.
2. Attach one of the provided tie wraps to an elevated point on the traction unit.
3. Assemble on end of the provided spring to the tie wrap located on the traction unit.
4. Assemble the opposite end of the hose spring to the tie wrap locate around the hoses.
