Technical data
10.08.99
YACE0060
49
RE 306 RE 307 RE 312 RE 320
Operating temperature range °C -20...200 -35...200 -30...200 -30...200
Ambient temperature range °C 5...40 (
#
Section 5.1.)
Setting resolution °C 0.01
Indication resolution °C 0.05
Indication accuracy ±0.2 °C
additive re-calibration
Temperature control ±°C 0.01 0.02 0.02 0.02
Safety features
FL
Additional function 2-line LCD-display and back-lightning. programmer
autom.
compressor
control
autom. compressor control + cooling adjustment
Heater
power
230 V; 50/ 60 Hz
115 V; 60 Hz
100 V; 50/60 Hz
kW 2.25
1.3
1.0
Cooling capacity (eff.)
@ with ethanol
at 20°C ambient
temperature
20°C
0°C
-20°C
-30°C
kW 0.20
0.15
0.05
----
0.30
0.22
0.10
0.06
0.30
0.23
0.13
0.04
0.35
0.25
0.10
0.04
Pump type pressure pump with choice of 5 output steps
Max. discharge pressure
Bar 0.4
Max. flow rate
l/min 17
Pump connections mm nipples 13 mm dia. ( M 16 x 1 )
Max. bath volume l 4 to 6 4 to 6 9 to 12 14 to 20
Bath opening (W x D) mm 150x130 150x130 200x200 300x350
Bath depth mm 160 160 200 160
Usable depth mm 140 140 180 140
Height top edge of bath mm 396 396 441 441
Overall size (W x D x H) mm 200x400x557 200x400x557 250x400x602 350x530x602
Weight kg 24 26 30 34
Power con-
sumption
230 V; 50/ 60Hz
115 V; 60 Hz
100 V; 50/60 Hz
kW 2.6
1.4
1.1
2.7
1.4
1.1
2.7
1.4
1.1
2.8
1.4
1.2
Ref. No. 230 V; 50/60
Hz
LCK 0866
230 V; 50 Hz LCK 1869 LCK 1872 LCK 1875
230 V; 60 Hz LCK 2869 LCK 2872 LCK 2875
115 V; 60 Hz LCK 4866 LCK 4869 LCK 4872 LCK 4875
100 V; 50/60 Hz LCK 6866 LCK 6869 LCK 6872 LCK 6875
*@ -10°C
FL suitable for flammable and non-flammable liquids
at pump output step 5
!
Section 7.2 last item
Units to EU Directive 89/336/EWG (EMC) and 73/ 23/ EWG (low-voltage) with CE-mark.
We reserve the right to make technical alterations!
