Pre
p
arations
16
DIN Safety data sheets are available on request!
Hose connections
a) Elastomer tubing
Tubing type Int. dia.
Ø mm
Temperature
range °C
Application Ref. No.
Perbunan tubing,
uninsulated
9 0 to 120 for all bath
liquids
RKJ 011
Perbunan tubing,
uninsulated
12 -0 to 120 for all bath
liquids
RKJ 012
Perbunan tubing
insulated
12
ext. dia.
35mm approx.
-60 to 120 for all bath
liquids
LZS 008
Silicone tubing,
uninsulated
11 -30 to 100 water,
water/glycol
mixture
RKJ 059
Silicone tubing
insulated
11
ext. dia.
35mm approx.
-60 to 100 water,
water/glycol
mixture
LZS 007
Viton 11 -60 to 200 for all bath
liquids
RKJ 091
Silicone oil causes pronounced swelling of Silicone rubber
!
never use Silicone
oil with Silicone tubing!
Protect tubing with hose clips against slipping off.
b) Metal hoses for Types RE 3xx, rust free stainless steel, with M 16 x 1 union nut 10 mm
int. Dia
Type
Length
cm
Notes Ref. No.
MC 50 50 With single insulation
LZM 040
MC 100 100 "
LZM 041
MC 150 150 "
LZM 042
MC 200 200 "
LZM 043
Pump connection link 20 "
LZM 044
MK 50 50 with foam insulation for low
temperatures
LZM 052
MK 100 100 "
LZM 053
MK 150 150 "
LZM 054
MK 200 200 "
LZM 055
Pump connection link 20 "
LZM 045
