28
−
with key back to "setpoint selection". (level 0).
6.4.4.4 Starting of the programmer
−
From level 0 proceed as described under 6.4.4. When
PGM appears on the display, press the key on the left.
−
The display shows RUN, or
−
forward with key from EDIT resp. LOOP until RUN
appears, then
−
start the programme with the key on the left. The setpoint
level (level 0) is then on display.
☞
−
During the start the current setpoint is accepted as the starting value.
−
If the programmer is activated:
level 0 shows PGM XXX.XX instead of SET XXX.XX (setpoint temperature), with
PGM flashing short
(short off, long on)
.
−
Setpoint can not be input with 0,01 °C resolution (only possible via RS 232
interface.)
−
General Rule: Programmer can also be loaded and operated via the RS 232
interface
