ID Function Unit Command
57 Control parameter XpF [–] IN_PAR_10
61 Control parameter Prop_E [K] IN_PAR_15
Table 17: Control
ID Function Unit Command
59 Set point oset [K] IN_PAR_14
67 Control in control variable X: 0 = internal / 1 = external Pt / 2 = external
analog / 3 = external serial / 5 = external Ethernet / 6 = external EtherCAT /
7 = external Pt 2 (only for Integral)
[–] IN_MODE_01
69 Oset source X for set point: 0 = normal / 1 = external Pt / 2 = external
analog / 3 = external serial / 5 = external Ethernet / 6 = external EtherCAT /
7 = external Pt 2 (only for Integral)
[–] IN_MODE_04
Table 18: Rights
ID Function Unit Command
63 Status of Master keyboard: 0 = free / 1 = blocked [–] IN_MODE_00
65 Status of remote control keyboard: 0 = free / 1 = blocked [–] IN_MODE_03
Table 19: Status
ID Function Unit Command
75 Status of standby: 0 = Device is switched on / 1 = Device is switched o [–] IN_MODE_02
107 Device type (e.g.: "INT" or "VC") TYPE
130 Device status: 0 = OK / -1 = fault [–] STATUS
131 Fault diagnosis; a 7-digit answer in the format XXXXXXX is output, whereby
each character X contains fault information (0 = no fault / 1 = fault).
The following information is defined for the seven places of the answer
format:
n 1st character = Error
n 2nd character = Alarm
n 3rd character = Warning
n 4th character = Overtemperature
n 5th character = Low level
n 6th character = 0 (with alarm setting: High level
n 7th character = External control value missing
[–] STAT
V6Integral Process Thermostats and High-Temperature Thermostats56 / 198
