LAUNCH X-431 PAD V User's Manual
7
2.4 Accessory Checklist
Common accessories for each X-431 PAD V are same, but for
different destinations, the accessories of X-431 PAD V (such as
diagnostic software, testing connectors) may vary. Please consult from
the local agency or check the package list supplied with X-431 PAD V
together.
Table 2-5 -- X-431 PAD V common accessories and descriptions
No. Name Qt. Picture
1 X-431 PAD V Tablet 1
2 VCI Device 1
(To connect to vehicle’s DLC.)
3 Docking Station 1
(Optional. To charge the tablet.)
4
Cigarette Lighter
Cable
1
(To supply power to non-16pin
dongle via vehicle’s cigarette
lighter receptacle.)
5 Power Adaptor 1
(To charge the tablet.)
6
Battery Clamps
Cable
1
(To provide power to the non-16
pin dongle through connection to
the vehicle's battery.)
7
OBD II extension
cable
1
(To connect the VCI device for
extension purpose.)
