LAUNCH TECH X-431 Torque - VCI Connector (Only Applies to 12 V Cars)

X-431 Torque User Manual
5
1 VOLUME +/- Key To adjust the volume.
2 POWER Key
In Off mode, press it for 3 seconds to turn the
handset on.
In On mode:
 Press it to activate the LCD if the LCD is off.
 Press it to turn off the LCD if the LCD lights up.
 Press it for 3 seconds to turn it off.
 Press it for 8 seconds to perform forced
shutdown.
3 LCD Screen
4 Speakers
5
USB/Charging
Port
 To connect to AC outlet for charging.
 To connect to PC for data exchange.
6
Adjustable
Kickstand
Flip out it to any angle and work comfortable at
your desk, or hang it on automotive part.
7 Rear Camera
2.3 VCI Connector (Only applies to 12V cars)
The VCI connector works as a vehicle communication interface device, which is
used to connect to the vehicle’s DLC (Data Link Connector) socket directly or via
OBD II extension cable to read the vehicle data and then send it to the X-431
Torque handset via Bluetooth.
