LAUNCH EasyDiag user’s guide
3. Connection and Installation
3.1 EasyDiag connection
Find out the vehicle’s DLC socket, plug EasyDiag into DLC socket
and the EasyDiag power indicator will light up.
Note: vehicle’s DLC socket is generally located under the
dashboard, in the fuse-box or near the shift lever. For the detail
position, please refer to corresponding vehicle’s repair manual.
Fig3.2
Near center of dashboard
3.2 Software download and install
EasyDiag app is free to download
Step 1: Turn on your smart terminals and link network well.
Step 2: Software store
iOS: App Store
Please go into app store, input keyword “EasyDiag” in the search
bar
, click” EasyDiag” (software client) to install (for details, please
refer to your equipment user’s manual) see Fig3.3.
4
