4.2.3 Function menu
It mainly includes the following items:
Name Description
Tradition Diagnose Configures the tablet to operate as a diagnostic tool.
Remote Diagnosis
This option aims to help repair shops or technicians
to get the repair job fixed faster.
Software Upgrade To update vehicle diagnostic software.
Maintenance Help
Includes How-to Videos, operation skills and user
manual etc.
Personal Center
Allows you to configure system settings and manage
your personal information.
4.3 Connections
4.3.1 Preparation
Normal testing conditions
 Turn on the vehicle power supply.
 Vehicle battery voltage range should be 9-14 Volts.
 Throttle should be in a closed position.
Select the VCI connector
If the tool is testing vehicles equipped with universal OBD II 16 PIN diagnostic
socket, please use the included VCI connector. (For vehicles with non-OBD II 16
PIN diagnostic socket, a non-16 PIN connector is required.)
4.3.2 DLC location
The DLC (Data Link Connector) is typically a standard 16-pin connector where
diagnostic tools interface with a vehicle’s on-board control modules. The DLC is
usually located 12 inches from the center of the instrument panel, under or
around the driver’s side for most vehicles. If DLC is not located under dashboard,
a label should be there telling location. For some Asian and European vehicles,
the DLC is located behind the ashtray and the ashtray must be removed to

Launch X-431 PROS MINI Specifications

General

RAM	2GB
Storage	16GB
Operating System	Android 7.0
Connectivity	Wi-Fi, Bluetooth
Processor	Quad-core
Battery	3000 mAh
Camera	5MP rear
Supported Protocols	OBDII, CAN
Vehicle Coverage	Over 100 brands
