1
Diagnostic socket
Connects the diagnostic cable
2
DC-IN power jack
Connects the cigarette lighter cable / battery
clamps cable.
3
LED Indicators
It is defined as follows:
 Vehicle: While communicating with the
vehicle, the indicator lights up and flashes.
Otherwise, it will not illuminate.
 Power: It illuminates solid red when the
module is powered on.
 Bluetooth: Blue indicates the module is
working in Bluetooth mode.
 USB: It lights up when the module is
