Launch X-431 V+ User Manual

LAUNCH X-431 V+ V4.0 User Manual
10
8
USB cable
1
9
OBD I adaptor box
For connecting the VCI connector and
non-16pin adaptor cable.
(Optional)
10
Non-16pin adaptor
cable kit
To connect to the vehicle equipped
with non-OBD II management system.
(Optional)
1.5.2 Commercial Vehicle Configuration
Accessories may vary depending on sales regions. Please consult local agency
or check the package list supplied with this tool.
No.
Item
Descriptions
Qt.
1
Display tablet
The central processor and monitor
for analyzing vehicle data and
showing test results.
1
2
VCI module
A device for accessing vehicle live
data.
1
3
Password
envelope
A piece of paper bearing Product
S/N and Activation Code, which is
required for your registration.
1
4
Diagnostic cable
To connect the VCI module to
vehicle’s DLC.
1
5
Cigarette lighter
cable
To supply power to the VCI module
through connection to cigarette
lighter receptacle.
(optional)
6
Battery clamps
cable
To supply power to the VCI module
through connection to vehicle’s
battery.
(optional)
7
Power adaptor
To charge the tablet through
connection to AC outlet.
1

Launch X-431 V+ Specifications

General

Screen Resolution	1280 x 800 pixels
Connectivity	Wi-Fi, Bluetooth
Operating System	Android
Display	Touchscreen
Battery	7000 mAh
Camera	5MP
Supported Protocols	OBD II, EOBD, CAN, etc.
Languages	Multiple languages
