LAUNCH X-431 V+ V4.0 User Manual
25
5 Diagnosis
5.1 Intelligent Diagnose
Through simple Bluetooth communication between the display tablet and the
VCI, you can easily get the VIN (Vehicle Identification Number) information of
the currently identified vehicle. Once the VIN is successfully identified, the
system will retrieve it from the remote server and then guide you to vehicle
information page without the necessity of step-by-step manual menu selection.
The vehicle information page lists all historical diagnostic records of the vehicle,
which lets the technician have a total command of the vehicle faults. In addition,
a quick dial to local diagnose and diagnostic function are also available on this
page for reducing the roundabout time and increasing productivity.
Note:
Before using this function, please make sure the VCI is properly connected to the
vehicle’s DLC. For detailed connection, see Chapter 4.3.3
Vehicle Connection
.
A stable network connection is required for this function.
Follow the steps below to proceed.
1. Tap
Intelligent Diagnose
on the Job menu screen.
Note: If the VCI is not paired up with the tablet before doing this step, a prompt
message box will appear on the screen. Check all the possible reasons of Bluetooth
connection failure carefully, and then tap
OK
to the following screen.
