LAVAZZA LB 2500 PLUS - CLEANING OF DRIP TRAY;USED CAPSULES DRAWER

33
EN
5
Pull out the mixer group.
6
Remove the mixer group nut.
7
Unhook the upper part of the mixer group from
the lower part.
8
Wash the components with cold or tepid water,
then dry and reassemble them correctly.
To reassemble the mixer group perform the opera-
tions described up to here in reverse.
MAINTENANCE AND CLEANING
CLEANING OF DRIP TRAY/USED CAPSULES
DRAWER
Cleaning of the drip tray/used capsules drawer
must be performed regularly and in any case every
time the display shows the following message:
LB2500 PLUS
Drawer full
If the capsules insertion drawer is opened when the
used capsules drawer is full, the display shows the
following message.
LB2500 PLUS
Empty drawer
1
Pull the complete drip tray/capsules drawer out.
The display shows:
LB2500 PLUS
Drawer open
2
Lift out the used capsules container and empty
it.
3
Pull the cup-support rack out and empty the
drip tray drawer.
