PAGE 4
SPECIFICATIONS
1.0 to 125 watt power range (SSB and CW), 100W on 6M.
Latching relays for ultra low power operation.
4,000 memories for instantaneous band changing.
Built-in 2-port antenna switch, with 2,000 memories each.
Tuning time 0.2 to 5 seconds full tune, 0.2 seconds memory tune.
1.8 to 54.0 MHz coverage. Built-in frequency sensor.
Tunes 6 to 1,000 ohm loads (16 to 150 on 6m).
LED bargraph displays power level, SWR, and status.
Antenna Indicator LEDs show the currently selected antenna.
User-selectable operating parameters: Auto/Semi, 125/12.5 watt scale, and more.
DC power cable included.
Power requirements: 11 to 16 VDC @ 500mA max. 7mA when idle.
Dimensions: 7.5” x 5.5” x 2.0”. Weight 1.5 pounds.
AN IMPORTANT WORD ABOUT POWER LEVELS
The AT-100ProII is rated at 125 watts maximum power input at most. Many ham
transmitters and transceivers, and virtually all amplifiers, output well over 125 watts. Power
levels that significantly exceed specifications will definitely damage or destroy your AT-
100ProII. If the tuner fails during overload, it could also damage your transmitter or transceiver.
Be sure to observe the specified power limitations.
IMPORTANT SAFETY WARNING
Never install antennas or transmission lines over or near power lines. You can be
seriously injured or killed if any part of the antenna, support, or transmission line touches
a power line. Always follow this antenna safety rule: The distance to the nearest power line
should be at least twice the length of the longest antenna, transmission line, or support
dimension.
