LDG AT-7000 - Specifications; Power Level Warnings; Critical Safety Warning

4
Specifications
•
0.1 to 125 watts SSB and CW peak power, 100 watts digital
• 2,000 memories for instantaneous frequency or band changing
• Tuning time: 0.5 to 6 seconds full tune, < 0.1 second memory tune
• Built in frequency counter for memory operation
• Frequency coverage: 1.8 to 54.0 MHz.
• Tunes 4 to 800 ohm loads (16 to 150 ohms on 6M), 4 to 3200 ohms with optional
4:1 Balun (LDG RBA-4:1)
• For Dipoles, Verticals, Vs, Beams or and Coax Fed Antenna
• Optional external Balun allows tuning of random length, long wire or ladder line
fed antennas
• Dedicated interface to the IC-7000 transceiver (and some other Icom radios)
• Power requirements: 11 to 16 volts DC at 250 mA max during tuning, < 8mA
idle, provided by the Icom transceiver
• Enclosure: 6.5 x 6.5 x 1.5 inches
• Weight: 1.5 pounds
An Important Word About Power Levels
The AT-7000 is rated at 125 watts maximum power input at most. Many ham transmitters and
transceivers, and virtually all amplifiers, output well over 125 watts. Power levels significantly
exceeding specifications will definitely damage or destroy your AT-7000. If your tuner fails
during overload, it could damage your transmitter or transceiver. Be sure to observe the specified
power limitations.
IMPORTANT SAFETY WARNING
Never install antennas or transmission lines over or near
power lines. You can be seriousl
y
in
j
ured or killed if an
y
part
of the antenna, support or transmission line touches a power
line. Alwa
y
s follow this antenna safet
y
rule: the distance to
the nearest power line should be at least twice the len
g
th o
f
the lon
g
est antenna
,
transmission line or su
pp
ort dimension.
