MAIN MENU
The landing page shows the current mode, time, state of alarm
and quick test index. Pause mode calculates the time that
remains before the system returns to its previous mode.
When you turn the device on, the system shows quick test
indexes in brackets which means that the shown value has not
been established yet.
Tightness test status page shows the status, the duration of
the analysis period and the longest pulseless period of the
tightness test. The alarm activates after a 24-hour analysis
period. The longest pulseless period can be used as a
reference if you wish to adjust Tightness test limits.
Flow test status page shows the status and the flow time of the
flow test. After the flow indicator turns off, it shows the flow
time of the last registered flow
Quick test status page shows the status and the index value of
the quick test. The maximum index limit of the quick test is
shown in brackets
ACTIVITY MENU
The menu contains a list of past activities. Each activity or
alarm will be saved in the system with its date, time and type
(WARN or ALRM). Cleared activities have been marked with
(CLR). The data is saved even if the system loses power.
STATUS MENU
The mode menu includes sensor data, AUX inputs and valves as well as AUX outputs.
Indicates registered pulses after installation or after restoring
factory settings. Current valve position (OPEN/CLOSED)
.
AUX input mode. If the port is configured for water metering,
and a pulse water meter is connected, the current meter
reading in litres is displayed here.
Measured volume according to the set times Minute Test and
Hour Test for the water meter connected to AUX1 in.
Measured volume according to the set times Minute Test and
Hour Test for the water meter connected to AUX2 in.
HOME HH:MM
OK 0.37
TIGHTN. TST OK
24h MAX=XX
FLOW TEST ALRM
00:33:29
QUICK TEST WARN
1.37 (1.00)
TIGHTN. TST
27/11 19:23 ALRM
SENSOR=19365
VALVE=OPEN
AUX1=LOW
AUX2=12345
VTT M1: 1234 L
VTM M1: 1234 L
VTT M2: 1234 L
VTM M2: 1234 L
