Leakomatic Pro1 - Input Handling Configuration; AUX Input Setup

17
Input handling
AUX1 in Indicates whether you prefer to switch between
the Home mode and the Away mode with a separate
button or with the burglar alarm. In other cases,
the input can be set to rise a warning or an alarm
from an external device, i.e. moisture sensor,
thermostat or pressure sensor. If a pulse water meter
is connected to the input, the water consumption
can be calculated. If ”Disabled”, no activity will be
registered through this input.
Disabled/
Water meter/
Home/
Away/
Warning/
Alarm
Sleep/Open/
Closed/Clear
AUX1 active Indicates whether the input will be activated when it
is high or low.
High/
Low
The settings below are only visible when the AUX1 in input is configured as water meter.
AUX1 pulse unit Specify the unit that is intended for the set value,
pulse size. This value must be set according to the
connected water meter’s technical specifications.
Liter/puls
Puls/liter
AUX1 pulse size Specify the quantity of water to which each pulse
from the water meter is equivalent. This value must
be set according to the connected water meter’s
technical specifications.
1–1000
(10)
AUX1 calibration Calibrate the value in the display unit for the current
water meter setting. Hold in the arrow-up button to
step through the values faster.
AUX2 in Specify the AUX2 input’s function.
See description above for AUX1 in.
Disabled/
Water meter/
Home/
Away/
Warning/
Alarm
Sleep/Open/
Closed/Clear
AUX2 active Specify if the input will be activated when it is high
or when it is low.
High/
Low
The settings below are only visible when the AUX2 in input is configured as water meter.
AUX2 pulse unit See description above for the AUX1 pulse unit.
Liter/puls
Puls/liter
AUX2 pulse size See description above for AUX1 pulse size.
1–1000 (10)
AUX2 calibration See description above for AUX1 calibration.
Analog input Select pressure or temperature sensor here, if a 4–20
mA analogue sensor has been connected.
Disabled/
Pressure
sensor/
Temp sensor
The settings below are only visible when the Analog input is configured as pressure or temp sensor.
Sensor min The sensor’s minimum measurement value.
Sensor max The sensor’s maximum measurement value.
