Learjet 25 - Airplane Dimensions

1-3
FOR TRAINING PURPOSES ONLY
LEARJET 20 SERIES PILOT TRAINING MANUAL
FlightSafety
international
41 FT
43 FT 3 IN.
14 FT 8 IN.
8 FT 3 IN.
34 FT 1 IN.
35 FT 7 IN.
45 FT
47 FT 7 IN.
12 FT
3 IN.
12 FT
3 IN.
MODELS 23 AND 24
ALL MODELS
MODEL 25
Figure 1-2. Airplane Dimensions
