7-20 Mechanical Parts & Removal
Assembly Note :
• Fan : Check the fan cable direction. Note the air flow, the fan extracts air from the
unit and expels it.
• Feet : Check that the lower feet and rear cord rack are aligned and properly
tightened before re-assembly.
• Floppy : Adjust the floppy position to obtain the front face tangential to face of
the front panel. Check that the door is moving freely and shuts correctly.
Insert a floppy and eject it to check the mechanism.
• Front Panel : Check that knobs rotate freely, are the right size and in the right
place. Do not forget the gasket, see Fig [H6].
• Main Board :The main card must be parallel and tacked against the bend of the
lower cover. Being careful not to bend the board or damage components
underneath.
• Processor : Check that the memory card insertion guide is correctly inserted in
the front panel.
• Printer : If the graphic printer is used, before closing don’t forget to plug input
cable to the option and the driver cable to the processor card.
