Lectrosonics D2 DSQD - Panels and Features; Front Panel Controls and Indicators; Rear Panel Connections and Ports

DSQD
LECTROSONICS, INC.
4
USB Port
Menu navigation
buttons
Power switch
Return to
previous screen
Panels and Features
IR Port
Headphone Volume
Adjustment
Headphone Jack
Reset Button
DSQD Front Panel
DSQD Rear Panel
Menu/Select
Channel Selector Buttons
Power Inlet
Dante Ports
Antenna B Input
50 Ohm BNC
XLR Analog Output
Connectors
Ethernet
Port
Antenna Bias
Power LEDs
Antenna A
Loop-thru Output
50 Ohm BNC
Multi-Frame
Communication
Antenna B
Loop-thru Output
50 Ohm BNC
Antenna A Input
50 Ohm BNC
