Model Description Digital 600 EX V
Capacity VA/W 600 VA/360 W
Input Voltage range 140-300 Vac
Frequency 50 Hz
Output Voltage 190-253 Vac
Voltage regulation (Batt. mode) 230 Vac +/- 10%
Frequency regulation (Batt. mode) 50 +/-1 Hz
Waveform Modified sine wave
Battery Battery type and number 12 V/7 Ah x 1 pc (sealed, lead-acid,
maintenance free, 6 cells battery)
Back up time (1 PC load) 10 min
Recharge time 4-8 hours to 90% after complete discharge
Transfer time Typical 4-8 ms, max 10 ms
Indicator AC mode Green lighting
Back up mode Green flashing
Audible alarm Back up mode Sounds every 10 seconds
Low battery Sounds every second
Overload Sounds 0.5 seconds
Fault Continuously sounds
Protection Full protection Discharge, overcharge and overload protection
Physical Dimension (DXWXH) 279 X 101 X 143 mm
Net weight 4.23 kg
Environment Operating environment 0-40°C, 0-90% relative humidity (non-condensing)
Noise level Less than 40 dB
*Product specifications are subject to change without further notice
SPECIFICATION
