7.1.5 Message statistics
The statistics section regarding the messages exchanged on the communication buses consists
of three different menus.
CAN STATISTICS SSW
MSG RX: 32564
100.0%
Number of messages received and percentage of reception accuracy regarding the status of the
static switches. The messages are exchanged between all the UPS units, therefore the number will
increase on all of them.
CAN STATISTICS INV
SYNC RX: 15849
100.0%
Number of messages received and percentage of reception accuracy regarding the synchronism
signals. The messages are sent by the MASTER UPS, therefore the number will only increase on
the SLAVE UPS units.
CAN STATISTICS INV
MSG RX: 9277
99.9%
Number of messages received and percentage of reception accuracy regarding the status of the
system. The messages are exchanged between all the UPS units, therefore the number will increase
on all of them.
7.2 SERVICE INFORMATION
The SERVICE menu provides important information regarding the technical service on the UPS.
The information is displayed via a text string of max. 60 characters which scrolls on the second
display line.
However, please also see the addresses and contact numbers indicated in the present manual.
