Leica BLK360 User Manual

Table of Contents
1 Safety Directions 6
1.1 General Introduction 6
1.2 Denition of Use 7
1.3 Limits of Use 7
1.4 Responsibilities 8
1.5 Hazards of Use 8
1.6 Laser Classication 11
1.6.1 General 11
1.6.2 Scanning Laser 12
1.7 Electromagnetic Compatibility (EMC) 12
2 Description of the System 15
2.1 System Components 15
2.2 Container Contents 15
2.3 Instrument Components 16
3 User Interface 17
3.1 Power Button 17
3.2 Instrument Status 17
4 Operation 19
4.1 Instrument Setup 19
4.1.1 General Information 19
4.1.2 Tripod Setup 19
4.1.3 Setup on a Surface 20
4.2 Operation - Getting Started 20
4.3 Imaging 23
4.3.1 Ambient Conditions 23
4.3.2 Field of View (FoV) 24
4.4 Scanning 24
4.4.1 Ambient Conditions 24
4.4.2 Troubleshooting 25
4.4.3 Field of View (FoV) 26
4.5 Data Transfer 26
4.6 Power Supply 27
4.6.1 Battery and Charger Safety 27
4.6.2 Charging Station 27
4.6.3 Internal Battery 29
5 Care and Transport 30
5.1 Maintenance 30
5.2 Transport 30
5.3 Storage 30
5.4 Cleaning and Drying 31
5.4.1 Air Inlet Cleaning Procedure 31
5.5 Laser Shield and Camera Lenses Cleaning Procedure 33
6 Technical Data 34
6.1 General Technical Data of the Product 34
6.2 System Performance 34
6.3 Laser System Performance 34
6.4 Electrical Data 37
6.5 Environmental Specications 37
6.6 Dimensions 38
6.7 Weight 39
6.8 Accessories 39
4 Table of Contents

Leica BLK360 Specifications

General

Measurement Range	0.6 - 60 m
Scan Speed	360, 000 points per second
Laser Class	Class 1
Thermal Camera	No
Laser Wavelength	830 nm
IP Rating	IP54
Connectivity	USB-C, Wi-Fi
Type	Laser scanner
Accuracy	4 mm at 10 m
Field of View	360° horizontal, 300° vertical
Camera	13 MP
Data Storage	Internal memory
Wireless Communication	Wi-Fi
Operating Temperature	0°C to +40°C
Imaging	High dynamic range (HDR) spherical imaging
Weight	1 kg
