Leica BLK360 User Manual

For data download, connect the BLK360 to a computing device using USB-C.
NEW ILLUSTRATION
0022107_001
1. Steps need to be reviewed and adapted.
Start the BLK360.
2. Connect the USB-C cable to the BLK360.
3. Connect the USB-C cable to the computing device.
4. Start the app and data can be downloaded.
4.3 Imaging
The BLK360 has 4 calibrated RGB cameras to collect LDR and HDR panoramic,
360° spheric images. The 4 cameras are also used for the Visual Inertial Sys-
tem (VIS).
013480_001
a
NEW ILLUSTRATION- 4 cameras
a 4 cameras
4.3.1 Ambient Conditions
•
Rain, snow or fog may adversely affect measurement quality. Always use
care when collect image data in these conditions.
•
Need input: dark surroundings /night
•
Need input: direct sunlight
Connecting to a com-
puting device using
USB-C
step-by-step
Description
Imaging
Ambient conditions
for imaging
Operation 23

Leica BLK360 Specifications

General

Measurement Range	0.6 - 60 m
Scan Speed	360, 000 points per second
Laser Class	Class 1
Thermal Camera	No
Laser Wavelength	830 nm
IP Rating	IP54
Connectivity	USB-C, Wi-Fi
Type	Laser scanner
Accuracy	4 mm at 10 m
Field of View	360° horizontal, 300° vertical
Camera	13 MP
Data Storage	Internal memory
Wireless Communication	Wi-Fi
Operating Temperature	0°C to +40°C
Imaging	High dynamic range (HDR) spherical imaging
Weight	1 kg
