GR30/GM30/GR50, GR50 User Interface
41
Please note the Bluetooth LED is only available on GR50 Bluetooth enabled
versions. GR50 with WLAN do not support Bluetooth.
RT in data stream
LED
off No active real-time in data stream or power is off.
green A real-time in data stream is configured and active,
data is received and a fixed position is available.
flashing
green
A real-time in data stream is configured and active,
data is received, a DGPS position is available.
yellow A real-time in data stream is configured and active,
data is received but no fixed or DGPS position is avail-
able.
red Incoming data streams are active but no data is
received.
OR
Incoming data stream is configured and active but
the instrument is not tracking satellites and/or no
position is available.
Recommended user action: Check that the
incoming data connection is set up correctly.
Check the tracking and position of the instru-
ment.
Position LED off The instrument is switched off.
flashing
green
The instrument is tracking satellites but no position
is available.
green A navigated position is available.
red No satellites are tracked and no navigated position is
available.
Bluetooth LED off No Bluetooth wireless signal (not configured or no
connection established).
blue Bluetooth connection configured and connected.
