Operation {A} inside front cover
1. Power Switch – Turns the detector on and off. Press to turn on or
off.
2. Accuracy Switch – Selects the detection accuracy. Press to select
fine or coarse setting.
3. Audio Switch – Selects the audio level. Press to select loud, soft or
off.
4. LCD Window – Front and rear LCD arrow displays indicate the
detector’s position.
5. Laser Reception Window – Detects the laser beam. The reception
window must be directed towards the laser.
6. Audio Speaker – Indicates the detector’s position.
• High – Fast beeping
• On-grade – Solid tone
• Low – Slow beeping
7. Mounting Hole – Location to attach the detector bracket.
8. Offset Notch – UUse to transfer reference marks. The notch is 45
mm (1.75”) below to top of the detector.
9. Product Label – Serial number and information.
10. Battery Door – Holds one 9-volt alkaline batteries. A new battery
must be installed in the position noted inside the battery compart-
ment.
Liquid Crystal Display {B} inside front cover
1. Grade Indication Arrows – Five channels are displayed: high, near
grade high, on-grade, near grade low, low.
2. Receiver Low Battery Warning – The low battery icon will appear
when the detector’s batteries are almost depleted.
3. Accuracy Indication – Two levels of accuracy are displayed: (a) fine,
(b) coarse.
4. Audio Volume Indication – Three settings are displayed: (a) loud,
(b) soft – icon blinking or (c) off - no icon.
