Adjustments
70
10.5 Rebound harrow
CAUTION
Loss of components, component collision
If the guide pins are not secured on the rebound harrow, they can
fall out due to vibrations in operation. This can cause the rebound
harrow to strike the rollers.
The guide pins must always be secured by linch pins.
The distance of the rebound harrows (1)
from the hollow discs can be adjusted as
well as its height and angle. The lower and
closer they are to the hollow discs, the mo-
re precisely they can collect and set down
the soil that is raised by the hollow discs.
A setting of the rebound harrows that is too low and too close can
result in clogging.
1
