25.3 – Serial port
ELECTRICAL INPUTS/OUTPUTS MAPPING
EAC/EAR UNITS
CLIMATIC™ 60 Main Board
SERIAL PORT
J6 Opt° Unit BMS Customer Bus
J7 Unit DS60 Terminal Display
J8 Unit CL60 external Bus
J9
J10 Unit CL60 internal Bus
