MUL41E-0610/06-2011 Page 5
5 - SCHEDULING ZONE ANTICIPATION
5.1 - Function
The CLIMATIC™ 60 allows the start up of the unit before the pre-specifyd hour of the first zone (Zone 1) of the day.
5.2 - Description
This function is able to start the unit in zone 1 earlier if the outdoor temperature is under a specify threshold. The
typical application is to start the unit in heating mode if the weather is too cold compare to the actual season.
Example :
• (2142): Start time zone 1 : 8h00,
• (2161): Anticipation foot : 10.0°C,
• (2162): Anticipation gradient: 10mm/°C.
In this example the foot is set to the value 10.0°C, which means the zone 1 will always start at 8h00 if the outside
air temperature is higher than 10.0°C. If the outside air temperature is less than 10.0°C the zone 1 will start
according to the gradient selected and the difference from the foot value and the actual outside air temperature
(10.0 - 7.0 = 3.0 x 10 = 30min). So the new start time for the zone 1 is 7h30.
5.3 - Settings
The different settings to adjust the anticipation are available in the menu:
• (2161): Anticipation foot.
• (2162): Anticipation gradient.
