CLIMATIC™ 60 – AIRCOOLED CHILLERS
Page 46 MUL41E-0610/06-2011
26 - SETTINGS LIST
Level 1 Item Level 2 Item Level 3 Item Level 4 Item R/W/Z Unit Min Std Max Description
1000 Alarm 1100 *** 1110 *** 1111 ***
2000 User 2100 Unit 2110 General 2111 On/Off R/W * 0 * 1 General On/Off
User Unit General 2112 Sw On/Off R * 0 * 1 Remote On/Off
User Unit General 2113 Run R/W/Z * 0 1 1 Enable
User Unit General 2114 Reset Alarm R/W * 0 0 1 Reset the active alarm(s)
User Unit General 2115 Clear Alarm R/W * 0 0 1 Clear the historic of alarm(s)
User Unit General 2116 Elec.Box R °C -50,0 * 105,0 Electrical box T°
User Unit General 2117 Status R * * * * General status
User Unit General 2118 Test R/W *
0=Not set,
1=Quickly,
2=Wizard,
3=Daily Task,
4=Weekly Task,
5=Defrost C1,
6=Defrost C2,
7=Defrost C1&2,
8=HP C1,
9=HP C2,
10=HP C1&2.
Test
User Unit General 2119 Restore R/W *
0=Not set,
1=DC+Bms,
2=Schedule,
3=Factory,
4=Store User,
5=Restore User.
Restore the settings
parameters
User Unit 2120 Clock 2121 Hour R/W HH 0 * 23 Hour clock setting
User Unit Clock 2122 Minute R/W mm 0 * 59 Minute clock setting
User Unit Clock 2123 Day R/W DD 1 * 31 Day clock setting
User Unit Clock 2124 Month R/W MM 1 * 12 Month clock setting
User Unit Clock 2125 Year R/W yy 1 * 99 Year clock setting
User Unit Clock 2126 Win/Sum R/W * 0 1 1
Automatic update for
winter/summer time
User Unit 2130 Schedule Status 2131 Weekday R D 1 * 7 Actual day of the week
User Unit Schedule Status 2132 Day R DD 1 * 31 Actual day of the month
User Unit Schedule Status 2133 Year R YY 1 * 99 Actual year
User Unit Schedule Status 2134 Hour R HH 0 * 23 Actual hour
User Unit Schedule Status 2135 Minute R mm 1 * 59 Actual minute
User Unit Schedule Status 2136 Zone R * 0 * 6 Actual schedule zone
User Unit Schedule Status 2137 Mode R * 1 * 5 Actual schedule mode
