CONSOLE NUMERIQUE KP02
Pressing key "V" displays the value of the selected data item.
Note: If the user does not press "V", the value appears automatically after 1 minute.
III.4. SET DATER mode
This mode can be used to adjust the 6 dater elements :
. hours and minutes ⇔
. the day of the month ⇔
. the day of the week ⇔
. the month ⇔
. the year ⇔
The element to be modified is selected as for READ DATER mode.
In the same way as for instructions, incrementation of the value is by simultaneously pressing keys "V" and "+"
and decrementation by simultaneously pressing "V" and "-".
For the different types of data, setting ranges are as follows :
Pressing key "A" saves the value entered.
Note: Months with less than 31 days are not automatically checked on entry. If a day is entered which is not
compatible with the current month, the value is refused at dater level and the old day is retained.
Examples:
Item Minimum value Maximum value
Hours and minutes 00-00H 23-59H
Day of the month 1 31
Day of the week 1 7
Month 1 12
Year
0 99
Day of the month
Current value Value entered Final value
02 (February) 15 30 15
10 (September) 26 31 31
