KP07 VDU CONSOLE
III.9. Tables of general variables
This screen gives access to the values of analogue inputs, logic inputs, TOR outputs, fault counters, and other
variables relating to the entire machine (not related to a specific refrigeration circuit). Each variable is identified
by its mnemonic.
III.9.a. Analogue inputs
This screen contains the temperatures associated with specific options (e.g.: temperature of hot water output
from heat recovery / temperature of chilled water output from free-cooling).
III.9.b. Logic inputs
This screen shows the states of contacts which have an effect on the overall operation of the machine
(e.g.: remote on / off, circuit breakers for pumps, choice of setting instruction, etc.)
