KP07 VDU CONSOLE
III.9.c. TOR outputs
This screen displays the state of the actuators which control machine components (other than those already
described in operating states for circuits and pumps).
III.9.d. Fault counters
Faults and fault counters associated with specific options appear on this screen.
III.9.e. other variables
This screen gives the values of calculated variables which apply to the entire machine. (e.g.: priority status for
pump operation, pump operation, idle functions, etc.)
