1.- GENERAL CHARACTERISTICS
1.6.- UNIT DIMENSIONS
SPLIT - STANDARD HORIZONTAL DISCHARGE
SPLIT - OPTIONAL VERTICAL DISCHARGE
Back view
Access to gas
and liquid lines
(C2)
Access to gas
and liquid lines
(C1)
Front view
Electrical box
Power supply
cable entry
External drainage
- 3/4” thread
External drainage
- 3/4” thread
