Lennox COMPACTAIR CSC - Unit Dimensions

12
CSC/CSH 20S/25S/30S/35S/40S/45D
23
A
30,5
C
B
345,5
25
929
47
33,5
41
D
D
E
30
020 - 025 - 030 S 035S - 040S - 045D
A 1194 1445
B 1000 1093
C 163,5 321,5
D 102,5 133
E 540 600
A
C
B
D
E
25
F
G
020 - 025 - 030 S 035S - 040S - 045D
A 371,5 420
B 564 622
C 288,5 403
D 1410 1500
E 204,5 252,5
F 467 543
G 77,5 74,5
CSC/CSH/CDC/CDH 55D/070D/85D
2251
143,5
143,5
953,5
345,5
25
929
47
33,5
23
41
98,5
98,5
670
57
953,5
373,5
518
493
1475
251,5
25
541
78,5
493
373,5
1.- GENERAL CHARACTERISTICS
1.6.- UNIT DIMENSIONS
Access to gas
and liquid lines
Power supply
cable entry
Electrical box
External drainage
- 3/4” thread
MODELS
“A” BOX “B” BOX
SPLIT - STANDARD HORIZONTAL DISCHARGE SPLIT - OPTIONAL VERTICAL DISCHARGE
MODELS
“A” BOX “B” BOX
Back view
Front view
SPLIT - STANDARD HORIZONTAL DISCHARGE SPLIT - OPTIONAL VERTICAL DISCHARGE
Access to gas
and liquid lines
(C2)
Access to gas
and liquid lines
(C1)
Back view
External drainage
- 3/4” thread
Electrical box
Power supply
cable entry
External drainage
- 3/4” thread
Front view
Power supply
cable entry
