Packaged Electric / Electric 26 to 44 kW 50 Hz / Page 10
OPTIONS / ACCESSORIES
ROOF CURBS
Field Installed
• 
• Mates to unit
• 
• Shipped knocked down

• Interlocking tabs fasten corners together
• No tools required
• Can also be fastened together with furnished hardware
• 
Adjustable Pitch Curb
• Fully adjustable pitch curbs (19 mm per 300 mm in
any direction) provide a level platform for rooftop units

sloped angles
• Uses interlocking tabs to fasten corners together
• No tools required
• Hardware is furnished to connect upper curb with lower
curb
• 
Adaptor Curbs (not shown)
• Curbs are regionally sourced
• Dimensions vary based upon the source
NOTE - Contact your local sales representative for a
detailed cut sheet with applicable dimensions.
CEILING DIFFUSERS
Field Installed
Ceiling Diffusers
(Flush or Step-Down)
• 
• Insulated UL listed duct liner
• Diffuser box has collars for duct connection
• 
• 
• Provisions for suspending
• Internally sealed to prevent recirculation
• Removable return air grille
• Adapts to T-bar ceiling grids or plaster ceilings
Transitions (Supply and Return)
• Used with diffusers
• Installs in roof curb
• 
• Flanges furnished for duct connection to diffusers
• Fully insulated
