Packaged Electric / Electric 26 to 44 kW 50 Hz / Page 26
BLOWER DATA
CEILING DIFFUSERS AIR RESISTANCE
RTD11 Step-Down Di󰀨user
FD11 Flush Di󰀨user
Unit Size
Air Volume 2 Ends Open
1 Side, 2 Ends
Open
All Ends & Sides
Open
Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g.
092 Models
1133 2400 52 0.21 45 0.18 37 0.15 35 0.14
1227 2600 60 0.24 52 0.21 45 0.18 42 0.17
1321 2800 67 0.27 60 0.24 52 0.21 50 0.20
1416 3000 80 0.32 72 0.29 62 0.25 62 0.25
1510 3200 102 0.41 92 0.37 80 0.32 77 0.31
1604 3400 124 0.50 112 0.45 97 0.39 92 0.37
1699 3600 152 0.61 134 0.54 119 0.48 109 0.44
1793 3800 182 0.73 157 0.63 142 0.57 127 0.51
102 & 120
Models
1699 3600 90 0.36 70 0.28 57 0.23 37 0.15
1793 3800 99 0.40 80 0.32 65 0.26 45 0.18
1888 4000 109 0.44 90 0.36 72 0.29 52 0.21
1982 4200 122 0.49 99 0.40 82 0.33 60 0.24
2076 4400 134 0.54 109 0.44 92 0.37 67 0.27
2171 4600 149 0.60 122 0.49 104 0.42 77 0.31
2265 4800 162 0.65 132 0.53 114 0.46 87 0.35
2360 5000 172 0.69 144 0.58 124 0.50 97 0.39
2454 5200 186 0.75 154 0.62 134 0.54 107 0.43
150 Models
1982 4200 55 0.22 47 0.19 40 0.16 25 0.10
2076 4400 70 0.28 60 0.24 50 0.20 30 0.12
2171 4600 85 0.34 72 0.29 60 0.24 37 0.15
2265 4800 99 0.40 85 0.34 72 0.29 47 0.19
2360 5000 114 0.46 97 0.39 85 0.34 57 0.23
2454 5200 129 0.52 109 0.44 97 0.39 67 0.27
2548 5400 144 0.58 122 0.49 107 0.43 77 0.31
2643 5600 159 0.64 134 0.54 117 0.47 87 0.35
2737 5800 174 0.70 147 0.59 127 0.51 97 0.39
CEILING DIFFUSER AIR THROW DATA
Model No.
Air Volume
1
E󰀨ective Throw Range
RTD11 Step-Down FD11 Flush
L/s cfm m ft. m ft.
092 Models
1227 2600 7 - 9 24 - 29 6 - 7 19 - 24
1321 2800 8 - 9 25 - 30 6 - 9 20 - 28
1416 3000 8 - 10 27 - 33 6 - 9 21 - 29
1510 3200 9 - 11 28 - 35 7 - 9 22 - 29
1604 3400 9 - 11 30 - 37 7 - 9 22 - 30
102, 120
Models
1699 3600 8 - 10 25 - 33 7 - 9 22 - 29
1793 3800 8 - 11 27 - 35 7 - 9 22 - 30
1888 4000 9 - 11 29- 37 7 - 10 24 - 33
1982 4200 10 - 12 32 - 40 8 - 11 26 - 35
2076 4400 10 - 13 34 - 42 9 - 11 28 - 37
150 Models
2643 5600 12 - 15 39 - 49 9 - 11 28 - 37
2737 5800 13 - 16 42 - 51 9 - 12 29 - 38
2831 6000 13 - 17 44 - 54 12 - 15 40 - 50
2926 6200 14 - 17 45 - 55 13 - 16 42 - 51
3020 6400 14 - 17 46 - 55 13 - 16 43 - 52
3115 6600 14 - 17 47 - 56 14 - 17 45 - 56
1
󰀨
minute. Four sides open.
