Packaged Electric / Electric 26 to 44 kW 50 Hz / Page 25
BLOWER DATA
FACTORY INSTALLED BELT DRIVE KIT SPECIFICATIONS
Nominal Maximum Drive Kit
Number
rev/min
Range
kW hp kW hp
1.5 2 1.7 2.3 1 490 - 740
1.5 2 1.7 2.3 2 665 - 920
1.5 2 1.7 2.3 3 660 - 995
2.2 3 2.6 3.45 7 610 - 810
2.2 3 2.6 3.45 8 780 - 1000
2.2 3 2.6 3.45 9 845 - 1085
3.7 5 4.3 5.75 10 750 - 945
3.7 5 4.3 5.75 11 865 - 1095
3.7 5 4.3 5.75 12 940 - 1190
NOTE - Using total air volume and system static pressure requirements determine from blower performance tables rev/min and motor output required. Maximum usable
output of motors furnished are shown If motors of comparable output are used, be sure to keep within the service factor limitations outlined on the motor nameplate.
POWER EXHAUST FAN PERFORMANCE
Return Air System Static Pressure Air Volume Exhausted
Pa in. w.g. L/s cfm
0 0 1498 3175
12 0.05 1394 2955
25 0.10 1267 2685
37 0.15 1137 2410
50 0.20 1022 2165
62 0.25 906 1920
75 0.30 670 1420
87 0.35 566 1200
FACTORY INSTALLED OPTIONS/FIELD INSTALLED ACCESSORY AIR RESISTANCE
Air Volume
Wet Indoor
Coil
Dry Indoor
Coil
Electric
Heat
Economizer
Humiditrol
Condenser
Reheat Coil
Filters
Return Air
Adaptor
Plate
092, 102,
120
150 150 MERV 8 MERV 13
L/s cfm Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g. Pa in. w.g.
1062 2250 32 0.13 45 0.18 30 0.12 10 0.04 20 0.08 5 0.02 2 0.01 10 0.04 0 0.00
1180 2500 37 0.15 55 0.22 35 0.14 10 0.04 27 0.11 7 0.03 2 0.01 12 0.05 0 0.00
1298 2750 42 0.17 57 0.23 37 0.15 12 0.05 30 0.12 7 0.03 5 0.02 12 0.05 0 0.00
1416 3000 47 0.19 70 0.28 45 0.18 15 0.06 32 0.13 7 0.03 5 0.02 15 0.06 5 0.02
1534 3250 57 0.23 82 0.33 52 0.21 15 0.06 37 0.15 10 0.04 5 0.02 15 0.06 5 0.02
1652 3500 65 0.26 92 0.37 57 0.23 22 0.09 37 0.15 10 0.04 7 0.03 17 0.07 10 0.04
1770 3750 72 0.29 104 0.42 65 0.26 22 0.09 37 0.15 12 0.05 7 0.03 20 0.08 17 0.07
1888 4000 77 0.31 112 0.45 70 0.28 22 0.09 47 0.19 12 0.05 10 0.04 20 0.08 22 0.09
2006 4250 85 0.34 124 0.50 80 0.32 32 0.13 47 0.19 15 0.06 10 0.04 22 0.09 27 0.11
2124 4500 92 0.37 132 0.53 82 0.33 35 0.14 55 0.22 17 0.07 10 0.04 22 0.09 30 0.12
2242 4750 99 0.40 147 0.59 92 0.37 42 0.17 62 0.25 17 0.07 12 0.05 25 0.1 40 0.16
2360 5000 107 0.43 157 0.63 99 0.40 50 0.2 72 0.29 20 0.08 15 0.06 25 0.1 45 0.18
2477 5250 114 0.46 169 0.68 104 0.42 55 0.22 80 0.32 20 0.08 15 0.06 27 0.11 47 0.19
2595 5500 124 0.50 182 0.73 114 0.46 62 0.25 85 0.34 22 0.09 17 0.07 30 0.12 55 0.22
2713 5750 139 0.56 196 0.79 124 0.50 77 0.31 112 0.45 25 0.10 17 0.07 30 0.12 62 0.25
2831 6000 147 0.59 214 0.86 134 0.54 82 0.33 129 0.52 25 0.10 20 0.08 32 0.13 67 0.27
